GDU S220 Pro 640 Thermal Standard Kit with 1x S200 Battery

GDU S220 Pro 640 Thermal Standard Kit with 1x S200 Battery

$5,999.00
$5,999.00
Sale Sold out
SKU S-GDU-S220T-PRO-640 MPN S220
  • Quad-sensor payload: wide, telephoto, thermal 640, laser
  • 640 × 512 thermal for dependable detection
  • Laser rangefinder 10–1500 m capability
  • 41 min flight endurance per 8000 mAh battery
  • Wide 50 MP and 48 MP tele with 160× zoom
  • RTK-ready for centimeter-level accuracy
  • Rugged IP43 protection, 720° obstacle avoidance
  • 15 km FCC transmission for HD video/data
  • Portable folding airframe for quick deployment
  • AI recognition detects people at 2 km, vehicles at 6 km
Request Info / Quote ☎︎ 1 (805) 480-4033
View full details
  • Description
  • Specifications
  • In the Box
  • FAQ

GDU S220 Pro 640 Version Standard Kit: Affordable Quad-Sensor Thermal Platform

The GDU S220 Pro 640 delivers the same quad-sensor versatility as the 1K model but with a 640 × 512 thermal payload, offering a cost-effective option for inspection and security missions.

Outfitted with a 50 MP wide camera, 48 MP telephoto with 10× optical zoom, a 640 thermal imager, and a 10-1500 m laser rangefinder, it enables operators to capture complete data in a single flight. With 41 minutes of endurance, RTK compatibility, and rugged IP43 durability, the S220 PRO 640 is ready for professional deployment.

Comprehensive Quad-Sensor Capability

The integrated payload provides detailed visual, thermal, and ranging data. Inspectors can zoom in with the telephoto, monitor heat signatures with thermal, and measure distances accurately with the laser rangefinder. AI-assisted recognition identifies people at 2 km and vehicles at 6 km, making it equally valuable for public safety and industrial operations.

Reliable Performance in the Field

With 41 minutes of flight time per battery, centimeter-level accuracy using RTK, and 15 km FCC video/data link, the S220 Pro 640 delivers reliable coverage in complex environments. Folding portability and all-direction obstacle sensing ensure ease of deployment and safer navigation, making it ideal for users seeking quad-sensor capability at a lower thermal resolution.

Key Features and Benefits

  • Quad-sensor payload: Wide, telephoto, thermal, and laser combined
  • Thermal imaging: 640 × 512 resolution for reliable thermal detection
  • Laser ranging: Distance measurement from 10-1500 m
  • 50 MP wide + 48 MP tele: High-resolution imaging with 160× zoom
  • Endurance: 41 minutes per intelligent battery
  • RTK-ready: Centimeter-level flight path and mapping precision
  • Rugged build: IP43 ingress protection for durability
  • All-direction obstacle avoidance: 720° sensing for safe operations
  • Long FCC range: 15 km secure transmission link
  • Compact folding design: Easy to transport and deploy

Applications and Use Cases

  • Industrial inspection: Utilities, pipelines, and energy infrastructure
  • Public safety: Tactical surveillance and evidence collection
  • Fireground support: Thermal detection of hotspots in fire scenes
  • Search and rescue: Locate people in low-visibility conditions
  • Infrastructure assessment: Bridges, tunnels, and facilities
  • Security patrols: Wide-area monitoring with AI detection
  • Environmental monitoring: Wildlife observation and terrain surveys
  • Hunting support: Spot game with thermal and visual sensors

The S220 Pro 640 combines quad-sensor capability with a 640 thermal payload for an affordable yet powerful aerial solution. Designed for adaptability, it supports both inspection and field operations with confidence.

Dronefly provides expert guidance and strong post-sale support for enterprise drone solutions. Order the S220 Pro 640 Standard Kit today.

  • Folded dimensions: 175 × 272 × 130 mm
  • Unfolded dimensions: 613 × 699 × 133 mm
  • Diagonal wheelbase: 486 mm
  • Aircraft weight (with battery): 1750 g
  • Max take-off weight: 2050 g
  • Max flight time: 45 minutes
  • Max ascent speed: 8 m/s
  • Max descent speed: 6 m/s
  • Max wind resistance: 12 m/s
  • Max service ceiling: 6000 m
  • Transmission range: 15 km (FCC), 8 km (CE/SRRC/MIC)
  • Wide-angle camera: 50 MP CMOS
  • Telephoto camera: 48 MP CMOS, 10× optical zoom, 160× hybrid zoom
  • Thermal camera: 640 × 512 @ 30 fps
  • AI recognition range: people up to 2 km, vehicles up to 6 km
  • Hover accuracy with RTK: ±1 cm + 1 ppm (horizontal), ±1.5 cm + 1 ppm (vertical)
  • Ingress protection: IP43
  • Obstacle sensing: 720° (all directions)
  • Intelligent flight battery: 8000 mAh (S200 series)



  • 1x Aircraft with battery, propellers, gimbal, and gimbal protector
  • 1x Remote controller
  • 1x Power adapter
  • 1x Single-cell charging hub
  • 1x Charging cable
  • 1x Spare propeller pair
  • 1x Protective case
  • 1x MicroSD card
  • 1x Screwdriver and tool kit
  • 1x Quick start guide, disclaimer, and documents
What imaging capabilities does the GDU S220 Pro 640 Version Standard Kit provide?

The GDU S220 Pro 640 Version Standard Kit includes wide, telephoto, thermal, and laser-ranging sensors. This quad-sensor system captures complete situational data in a single flight.

How long can the GDU S220 Pro 640 Version Standard Kit operate per battery?

The intelligent battery supplies up to 41 minutes of flight time. This enables extended operations for inspections, public safety, and environmental monitoring.

Does the GDU S220 Pro 640 Version Standard Kit support RTK workflows?

Yes. The aircraft is RTK-ready and can achieve centimeter-level accuracy. This supports precise mapping, repeatable surveys, and accurate structural assessments.

What detection ranges does the GDU S220 Pro 640 Version Standard Kit support?

AI-assisted detection identifies people at up to 2 km and vehicles at up to 6 km. This makes it effective for wide-area security, monitoring, and tactical response missions.

Is the GDU S220 Pro 640 Version Standard Kit suitable for rugged environments?

Yes. Its IP43-rated design and 720° obstacle sensing provide reliable performance outdoors. Combined with long-range transmission, it is suited for demanding field deployments.
