DJI Matrice 4D Aircraft Only

DJI Matrice 4D Aircraft Only

$5,556.00
$5,556.00
Sale Sold out
  • Long-Lasting & Weatherproof: Up to 47 minutes of flight time and IP55 rating for all-weather missions.
  • Triple-Camera System: Features a mechanical shutter and up to 48MP tele lens for crisp, detailed imagery.
  • Advanced Obstacle Avoidance: LiDAR and radar with 12mm wire detection ensure safer, AI-assisted flights.
  • Enhanced Night Vision: Four low-light fisheye lenses and Night Scene Mode deliver clear, full-color images.
  • Efficient Autonomous Operations: Seamless DJI Dock 3 integration enables self-guided flights, recharging, and cloud-based mission planning.
Request Info / Quote ☎︎ 1 (805) 480-4033
View full details
  • Description
  • Specifications
  • In the Box
  • FAQ

DJI Matrice 4D: Elevating Performance, Precision, and Automation

The arrival of the cutting-edge DJI Dock 3 introduces two powerhouse drones—the DJI Matrice 4D and DJI Matrice 4TD—engineered for round-the-clock autonomous operations. These models extend the capabilities of the Matrice 4 Series, delivering superior flight performance, resilience, and imaging technology.

While both drones offer outstanding features, the DJI Matrice 4D stands out as a comprehensive solution for high-precision mapping, inspections, and specialized missions. Explore its key functionalities below.

Key Features of the DJI Matrice 4D

Crafted for professionals who demand precision, efficiency, and durability, the DJI Matrice 4D redefines commercial drone standards with its advanced capabilities.

Exceptional Flight Performance

  • Wind Resistance: Operates steadily in winds up to 12 m/s.
  • Extended Flight Duration: Offers a maximum flight time of 47 minutes, extending to 54 minutes in forward flight.
  • IP55 Rating: Built to withstand dust and water exposure for all-weather operations.
  • Anti-Ice Propellers: Maintains efficiency in freezing rain with low-noise performance.

Next-Generation Imaging System

  • Wide-Angle Camera: Features a 4/3 CMOS sensor, 20MP resolution, and a mechanical shutter for high-clarity imaging.
  • Medium Tele Camera: Equipped with a 1/1.3-inch CMOS sensor and 48MP resolution for mid-range inspections.
  • Tele Camera: Houses a 1/1.5-inch CMOS sensor, 48MP resolution, and a zoom capacity up to 250m.
  • Laser Range Finder: Measures distances up to 1,800m with pinpoint accuracy.
DJI Matrice 4D camera system

Advanced Safety and Obstacle Avoidance

  • LiDAR and millimeter-wave radar ensure 12mm-level wire detection for safe navigation.
  • Multi-directional obstacle sensing enhances maneuverability in low-light environments.
  • AI-assisted flight and smart tracking optimize subject detection and monitoring.

Enhanced Night Vision and Stability

  • Four low-light fisheye lenses provide exceptional nighttime visibility.
  • Night Scene Mode: Captures full-color imagery in low-light conditions.
  • Advanced stabilization: Ensures steady imaging even during high-zoom operations.

Seamless Integration with DJI Dock 3

Pairing the DJI Matrice 4D with DJI Dock 3 unlocks unmatched efficiency and automation for remote drone operations.

  • 24/7 Autonomous Missions: Enables self-sustained takeoff, landing, and recharging.
  • Cloud-Based Mission Planning: Utilize DJI FlightHub 2 for automated flight path management.
  • Flexible Deployment: Operates from fixed locations or mobile vehicle-mounted docks for rapid response.
  • Dual-Drone Coordination: Supports continuous aerial surveillance with multi-drone synchronization.

Industry Applications

The DJI Matrice 4D serves a diverse range of industries with its advanced capabilities.

Public Safety and Emergency Response

  • Search and Rescue: Identifies missing persons using high-resolution imaging.
  • Firefighting: Assesses wildfires and hazardous zones in real time.

Infrastructure and Industrial Inspections

  • Energy Sector: Inspects power lines, substations, and renewable energy facilities.
  • Roads and Bridges: Evaluates structural conditions safely and efficiently.
  • Oil and Gas: Conducts pipeline and refinery inspections with minimal downtime.

Mapping and Surveying

  • Geospatial Mapping: Generates 3D models and high-accuracy orthophoto maps.
  • Urban Planning: Collects critical data for city infrastructure development.
  • Water Resource Management: Monitors dam safety and flood-prone areas.

Maritime and Border Patrol

  • Coastal Surveillance: Detects illegal activities and environmental changes.
  • Port Security: Monitors vessels and infrastructure for compliance and safety.

The DJI Matrice 4D represents the next generation of commercial drone technology, offering unparalleled precision, reliability, and automation.

Whether integrated with DJI Dock 3 for autonomous missions or deployed independently with DJI RC Plus 2 Enterprise, it provides unmatched aerial intelligence for a wide range of industries.

  • Takeoff Weight (with propellers): 1850 g
  • Max Takeoff Weight: 2090 g
  • Dimensions: 377.7 × 416.2 × 212.5 mm (L×W×H, without propellers)
  • Wheelbase: Diagonal Wheelbase: 498.5 mm
  • Max Ascent Speed:

    6 m/s (N Mode)
    10 m/s (S Mode)

  • Max Descent Speed:

    6 m/s (N Mode)
    8 m/s (S Mode)

  • Max Horizontal Speed (at sea level, no wind):

    Normal Mode (Obstacle Sensing Enabled): 15 m/s forward, 12 m/s backward, 10 m/s sideways
    Sport Mode: 21 m/s forward, 19 m/s backward, 15 m/s sideways

    *When used with DJI Dock, only Normal mode is supported.
  • Max Wind Speed Resistance:

    During Operation: 12 m/s
    During Takeoff/Landing: 12 m/s

  • Max Takeoff Altitude: 6500 m
  • Operating Temperature: -20° to 50°C (-4° to 122°F)
  • Ingress Protection Rating: IP55
  • Max Flight Time (no wind): 54 minutes
  • Max Hover Time (no wind): 47 minutes
  • GNSS: GPS + BeiDou + Galileo + QZSS + GLONASS (QZSS and GLONASS supported only with RTK module)
  • RTK Module: Built-in, no installation required
  • Cellular Dongle 2 Compartment: Yes
  • AI Detection: Yes
  • Wide Angle Camera:

    Sensor: 4/3 CMOS, 20 MP
    Lens: FOV: 84°, 24 mm eq., Aperture: f/2.8-f/11, Focus: 1 m to ∞
    Night Scene Mode: Full-Color Night Scene
    ISO Range: 100-25600 (Night Scene: 100-204800)
    Shutter Speed: Electronic: 2-1/8000 s, Mechanical: 2-1/2000 s
    Max Photo Size: 5280 × 3956
    Still Photo Modes: Single, Timed, Smart Low-Light, Panorama
    Min Photo Interval: 0.5 s
    Photo Format: JPEG/DNG (RAW)
    Video: H.264/H.265; 4K 30fps, FHD 1080p 30fps; Format: MP4

  • Medium Tele Camera:

    Sensor: 1/1.3-inch CMOS, 48 MP
    Lens: FOV: 35°, 70 mm eq., Aperture: f/2.8, Focus: 3 m to ∞
    Night Scene Mode: Full-Color Night Scene
    ISO Range: 100-25600 (Night: up to 409600)
    Shutter Speed: 2-1/8000 s
    Max Photo Size: 8064 × 6048
    Still Photo Modes: Single (12MP/48MP), Timed, Smart Capture
    Photo Format: JPEG
    Video: H.264/H.265; 4K 30fps, FHD 1080p 30fps; Format: MP4

  • Tele Camera:

    Sensor: 1/1.5-inch CMOS, 48 MP
    Lens: FOV: 15°, 168 mm eq., Aperture: f/2.8, Focus: 3 m to ∞
    Night Scene Mode: Full-Color Night Scene
    ISO Range: 100-25600 (Night: up to 409600)
    Shutter Speed: 2-1/8000 s
    Max Photo Size: 8192 × 6144
    Still Photo Modes: Single (12MP/48MP), Timed, Smart Capture
    Photo Format: JPEG
    Video: H.264/H.265; 4K 30fps, FHD 1080p 30fps; Format: MP4

  • Digital Zoom: 16x (112x hybrid zoom)
  • Infrared Thermal Camera: Not Available / N/A
  • NIR Auxiliary Light: N/A
  • Laser Rangefinding: Normal: 1800 m, Oblique: 600 m, Blind Zone: 1 m
  • Measurement Accuracy: 1-3 m: <0.3 m system error, <0.1 m random error; others: ±(0.2+0.0015D)
  • Sensing Type: Omnidirectional binocular vision + 3D infrared sensor
  • Video Transmission System: DJI O4+ Enterprise
  • Live View Quality: Up to 1080p/30fps
  • Operating Frequency: 2.4GHz, 5.1GHz, 5.8GHz (varies by region)
  • Max Transmission Distance: FCC: 25 km; CE/SRRC/MIC: 12 km
  • Transmission in Interference: 1.5-25 km depending on environment
  • Max Download Speed: 20 MB/s
  • Latency: ~100 ms aircraft to dock (variable)
  • Antenna: 8 antennas, 2T4R
  • Cellular Dongle Support: DJI Cellular Dongle 2
  • Remote Controller:

    Screen Resolution: 1920 × 1200
    Screen Size: 7.02 inches
    Brightness: 1400 nits
    Storage: 128GB internal + microSD expansion
    Operating Time: Built-in: 3.8 hrs, External: 3.2 hrs
    External Battery: Supported
    Output Port: HDMI
    Model: TKPL 2

  • 1x DJI Matrice 4D Aircraft (Battery Not Included)
  • 1x CW Low-Noise Anti-Ice Propellers (Pair)
  • 1x CCW Low-Noise Anti-Ice Propellers (Pair)
  • 1x Screws and Washers
What is the IP rating of the Matrice 4D Series?

Both Matrice 4D and Matrice 4TD are rated IP55 for dust and water resistance. This means the aircraft is designed to operate in rainy and dusty conditions.

What’s the main difference between the Matrice 4D and Matrice 4TD?

The key difference is in the sensor/camera configuration:

  • The Matrice 4D is optimized for high-precision mapping with a 4/3” 20 MP wide-angle camera plus medium-tele and tele cameras.
  • The Matrice 4TD swaps in a thermal-imaging camera (infrared) in addition to a 48 MP wide-angle (1/1.3” CMOS) and the same medium tele and tele cameras, making it more oriented to inspections, search/rescue, thermal tasks.
What is the primary use case for Matrice 4D vs Matrice 4TD?

Matrice 4D: Best suited for high-precision mapping, surveying, and infrastructure tasks where high-res visible cameras and laser range measurement matter.

Matrice 4TD: Best for inspections, search and rescue, thermal monitoring etc., thanks to the added thermal camera and near-infrared light support.

What remote controllers are compatible with Matrice 4D Series drones?
  • DJI RC Plus 2 Enterprise Remote Controller
  • DJI RC Plus 2 Enterprise Enhanced Version
