Autel EVO II Battery Charging Hub

Autel EVO II Battery Charging Hub

$89.00
$89.00
Sale Sold out
SKU S-AR-E2-MCHG MPN 102000204 UPC 889520010924
  • Four-slot design supports multi-battery charging in one system
  • Dual charging modes support simultaneous and alternate operation
  • Charges 2 batteries first before sequentially charging remaining units
  • 5.5-hour total cycle supports full battery charging rotation
  • Requires standard EVO II charger for external power input
  • 13.2 V input ensures compatibility with EVO II charging system
  • LED indicator provides real-time charging status and feedback
  • Red alert system detects abnormal voltage and temperature conditions
  • Compatible with EVO II, Pro, Dual 640T, Enterprise, RTK batteries
Request Info / Quote ☎︎ 1 (805) 480-4033
View full details
  • Description
  • Specifications
  • In the Box
  • FAQ

Multi-Battery Charging Hub for EVO II Series Batteries

The Autel EVO II Battery Charging Hub is designed to manage charging across multiple EVO II batteries using a single external charger. It supports up to four batteries and operates using two charging modes: simultaneous charging for two batteries and alternate charging for the remaining units.

The hub requires the standard EVO II charger and does not include its own power supply. Built-in LED indicators display charging status and system conditions, including alerts for abnormal voltage or temperature, allowing users to monitor the charging process in real time.

Key Features and Benefits

  • Four-battery capacity: supports charging up to 4 EVO II batteries
  • Dual charging modes: supports simultaneous and alternate charging operation
  • Two-battery charging: charges 2 batteries simultaneously before rotation
  • Sequential charging: continues charging remaining batteries automatically
  • 5.5-hour total time: completes full 4-battery charging cycle
  • External charger required: uses standard EVO II charger, not included
  • 13.2 V operation: matches EVO II charging system requirements
  • LED status indicator: displays charging progress and system feedback
  • Error alert system: red light indicates voltage or temperature issues

The hub provides a structured approach to charging multiple batteries without requiring additional chargers. Its dual-mode charging behavior helps manage charging cycles efficiently across all connected batteries.

With Dronefly, you can maintain a consistent and reliable charging setup for your drone system. Order the Autel EVO II Battery Charging Hub from Dronefly today.



  • Working Voltage: 13.2V
  • Working Temp.: 41-104°F (5-40°C)
  • Reference Charging Time (4 batteries): 5.5h
  • 1x Autel EVO II Battery Charging Hub
How does the Autel EVO II Battery Charging Hub work?

The hub distributes power from a single charger across multiple batteries. It charges two batteries at once, then continues with the remaining batteries. This allows efficient battery management.

Does the Autel EVO II Battery Charging Hub include a power adapter?

No, it does not include a power adapter. It requires the standard EVO II charger that comes with the drone. This is necessary for operation.

Can the Autel EVO II Battery Charging Hub charge different battery types?

Yes, it supports multiple EVO II battery types including standard, Pro, Dual 640T, Enterprise, and RTK batteries. This ensures flexibility across different setups. It is compatible across the EVO II series.

Is the Autel EVO II Battery Charging Hub useful for multiple flights?

Yes, it helps manage charging across several batteries in one system. This reduces downtime between flights. It is useful for extended operations.

How does the Autel EVO II Battery Charging Hub show charging status?

It uses an LED display to show charging progress. A red light indicator alerts users to voltage or temperature issues. This provides clear system feedback.
