WISPR SkyScout 2 Series: Configurable American-Made UAV Platforms for Enterprise Survey, LiDAR, and Multispectral Operations
The WISPR SkyScout 2 Series enters the professional UAV market as a fully American-made, NDAA-compliant platform engineered for enterprise deployment at scale. Listed on both the Blue UAS Cleared List and the Green UAS Program, the SkyScout 2 Series is built around a compact quadcopter airframe that supports a broad modular payload ecosystem spanning photogrammetry, LiDAR, multispectral, and precision survey configurations through a single S Port quick-attach interface. For fleet operators and solutions integrators, this means one airframe, one training footprint, and a payload library that adapts to mission type without requiring a separate platform for each application.
The series is offered in two configurations: the SkyScout 2 (Base Package) paired with the Herelink controller, and the SkyScout 2+ (Premium Package) paired with the WISPR SkyBoss Smart Controller. Both run the same airframe, flight firmware, GNSS architecture, and battery system. The controller selection drives the encryption tier, display ruggedness, and procurement compliance level — critical variables for enterprise programs operating under federal, state, or defense procurement requirements.
SkyScout 2 and SkyScout 2+: Configuration Differences and Procurement Considerations
The two packages share an identical airframe and flight performance envelope. Controller selection determines the security profile, display capability, and compliance tier of each deployment.
Scroll to view full table →
| Specification | Base Package SkyScout 2 | Premium Package SkyScout 2+ |
|---|---|---|
| Aircraft weight | 5.3 lbs. (2.4 kg) | 5.5 lbs. (2.5 kg) |
| Max takeoff weight | 12 lbs. (5.4 kg) | 12.2 lbs. (5.5 kg) |
| Max sustainable payload | 3.85 lbs. (1.75 kg) | 3.85 lbs. (1.75 kg) |
| Max flight time (no payload) | 35 min | 35 min |
| Max flight time (2.2 lb payload) | 30 min (+/- 2 min) | 30 min (+/- 2 min) |
| Max speed / wind rating | 50 MPH (80 km/h) | 50 MPH (80 km/h) |
| Operating temperature | -4°F to 122°F (-20°C to 50°C) | -4°F to 122°F (-20°C to 50°C) |
| Controller included | Herelink (Black or Blue) | WISPR SkyBoss Smart Controller |
| Controller display | 5.5" LCD, 1000 nits | 7" LCD, 2000 nits (sunlight readable) |
| Controller roll wheels | Single | Dual |
| Controller IP rating | — | IP55 |
| Controller drop test | — | MIL-STD-810 passed |
| Controller runtime | — | ~6 hr (hot-swappable batteries) |
| Transmission encryption | AES128 | AES-256 |
| Frequency | 2.4 GHz over LTE | 2.4 GHz and 5 GHz |
| Control range | 12 miles (19.3 km) | 5 miles (8 km) |
| Antennas | 2 | 4 |
| Extra GNSS antenna mount (LiDAR) | — | ✓ Included |
| NDAA compliant | ✓ | ✓ |
| Blue UAS Cleared | ✓ | ✓ |
| Green UAS Listed | ✓ | ✓ |
| Made in America | ✓ | ✓ |
Platform Specifications: Airframe, GNSS, and Battery System
The SkyScout 2 airframe is consistent across both packages, with all mission-critical systems shared between configurations. The Ublox ZED-F9P GNSS receiver provides multi-constellation positioning across L1, L2, and E5 bands with native RTK and PPK capability. The Cube Orange + flight controller runs WISPR Flight Firmware, a custom ArduPilot build maintained by WISPR Systems and validated across survey, LiDAR, and inspection workflows.
Scroll to view full table →
| Specification | Value — Both Models |
|---|---|
| Frame type | Quad Copter |
| Flight controller | Cube Orange + |
| Firmware | WISPR Flight Firmware (custom ArduPilot build) |
| Folded dimensions | 4.5" x 10" x 17" (11.4 cm x 25.4 cm x 43.2 cm) |
| Fully assembled dimensions | 14" x 24" x 24" (35.6 cm x 61 cm x 61 cm) |
| Diagonal wheelbase | 32.5" props folded; 49" props unfolded (82.6 cm / 124.5 cm) |
| Propeller size | 18.2" x 5.9" (46.2 cm x 15 cm) |
| Collision avoidance | Front, backward, downward |
| Terrain follow source | GNSS (high altitude); LiDAR Range Finder (low altitude) |
| I/O ports | MicroUSB (flight controller access); USB-C (GPS logs storage) |
| Orientation LED | Red (rear), White (front) |
| GNSS receiver | Ublox ZED-F9P |
| GNSS bands | L1, L2, and E5 |
| GNSS constellations | GPS + Galileo + GLONASS + BeiDou |
| IMU | Built-in 9-axis |
| RTK compatible | Yes — NTRIP or other RTCM services |
| PPK compatible | Yes — with WISPR Cloud Subscription |
| Battery configuration | 2 x WISPR Smart Batteries |
| Battery voltage | 22.8V |
| Battery capacity | 4350mAh (99.18 Wh) |
| Battery weight | 1.4 lbs. (630g +/- 20g) |
| Charging time | 45 minutes |
| Setup time | Under 3 minutes |
| Made in America | Yes |
Payload Ecosystem, Integration Architecture, and Ground Support Hardware
The S Port quick-attach system is the integration backbone of the SkyScout 2 Series. A single plug delivers both power and data to any compatible payload, enabling field swaps without tools and without incurring flight-time penalties on payloads up to 3.65 lbs. For fleet programs, this architecture means operators can maintain one airframe inventory and reconfigure missions — from photogrammetry to LiDAR to multispectral — by swapping payloads rather than platforms. The SkyScout 2+ adds a dedicated extra GNSS antenna mount for LiDAR payload integration, supporting precise georeferencing on RESEPI-series configurations.
Scroll to view full table →
| Category | Compatible Payload |
|---|---|
| Photogrammetry / Mapping | WISPR 24MP Mapper |
| Photogrammetry / Mapping | Sony LR1 (61MP) on Custom Gimbal — 35mm lens |
| Photogrammetry / Mapping | Sony LR1 (61MP) on Custom Gimbal — 50mm lens |
| Photogrammetry / Mapping | Sony LR1 (61MP) 35mm lens with 200m Laser Rangefinder |
| Agriculture / Multispectral | Sony LR1 Agrowing Sextuple Lens |
| Agriculture / Multispectral | Sony LR1 Agrowing Quad Lens |
| Agriculture / Multispectral | Micasense RedEdge-P |
| Agriculture / Multispectral | Micasense RedEdge-P Dual |
| Gimbal Platforms | Gremsy Zio (SkyScout) |
| Gimbal Platforms | Gremsy Vio F1 (SkyScout) |
| Gimbal Platforms | Gremsy Vio G1 (SkyScout) |
| LiDAR / Sensor — with FPV Gimbal | RESEPI Lite-M2X 24MP Camera |
| LiDAR / Sensor — with FPV Gimbal | RESEPI Avia Livox 24MP Camera |
| LiDAR / Sensor — with FPV Gimbal | RESEPI Ultra Lite-XT32 5MP Camera |
| LiDAR / Sensor — with FPV Gimbal | RESEPI Ouster REV7 OS1-64 26MP Camera |
| LiDAR / Sensor — no FPV Gimbal | RESEPI Teledyne EchoONE 5MP Camera |
| LiDAR / Sensor — no FPV Gimbal | RESEPI Gen-II Ouster OS1-64 61MP Camera |
All payloads connect via S Port quick-attach — single-plug power and data, no tools required. Maximum payload with no flight-time penalty: 3.65 lbs. Maximum sustainable payload: 3.85 lbs.
Ground support hardware for the SkyScout 2 Series includes the SkyScout Battery Charger (45-minute charge time per battery pair), the SkyBoss Battery for the SkyScout 2+ package, and the WISPR Systems carry case with roll wheels and handle (32.4" x 18.5" x 10.85", 3.75 cu. ft., 17.6 lbs. empty, 37 lbs. fully loaded).
Key Features and Operational Capabilities
- S Port quick-attach integration: one-plug power and data interface enables tool-free payload swaps across the full compatible lineup with no flight-time penalty up to 3.65 lbs.
- TerrainSense altitude hold: dual-source terrain following via GNSS at altitude and LiDAR Range Finder at low altitude maintains mission accuracy across variable terrain profiles
- SmartCore power architecture: redundant power distribution with active battery-failure protection sustains uninterrupted operations through single-battery degradation events
- PathGuard obstacle detection: front and rear sensing to 164 ft (50 m) protects both outbound flight paths and return-to-home routes
- TempGuard thermal regulation: active airflow management maintains avionics within operational spec across the full -4°F to 122°F (-20°C to 50°C) envelope
- SignalShield EMI shielding: hardened avionics protection supports reliable operations near power transmission infrastructure and communication towers
- Multi-constellation RTK: Ublox ZED-F9P with GPS, Galileo, GLONASS, and BeiDou support via NTRIP or RTCM for centimeter-level real-time positioning
- PPK workflow support: post-processed kinematic capability via WISPR Cloud for sites with limited or unreliable correction network coverage
- Hot-swappable smart batteries: field battery exchange without powering down; 22.8V, 4350mAh (99.18 Wh), 45-minute charge time, airline-compliant
- Sub-three-minute deployment: ruggedized carry case with roll wheels and handle supports rapid site-to-site transitions and fast mission launch
- NDAA compliant and American-made: procurement-ready for federal, state, and defense programs; Blue UAS Cleared and Green UAS Listed
Deployment Scenarios and Enterprise Use Cases
- Fleet survey programs: single airframe type across the fleet with swappable payloads reduces maintenance complexity and cross-training requirements
- Cadastral and topographic survey: RTK and PPK positioning with high-resolution photogrammetry payloads supports boundary, elevation, and site survey deliverables
- LiDAR corridor and terrain mapping: RESEPI payload compatibility with dedicated LiDAR GNSS antenna mount on the SkyScout 2+ enables high-density point cloud acquisition
- Precision agriculture programs: Micasense RedEdge-P and Sony LR1 Agrowing configurations support multispectral data collection across large agricultural areas
- Government and public safety deployments: NDAA compliance, AES-256 encryption on the SkyScout 2+, and Blue UAS / Green UAS status satisfy federal and defense procurement requirements
- Construction and site monitoring: repeatable autonomous flight paths combined with RTK accuracy support volumetric analysis and progress documentation workflows
- Infrastructure inspection: compact airframe, PathGuard obstacle sensing, and SignalShield EMI protection support close-range inspection near high-voltage infrastructure
Software Ecosystem and Enterprise Workflow Integration
Both SkyScout 2 configurations operate on WISPR Flight Firmware, a custom ArduPilot build designed specifically for the SkyScout platform. Ground operations and mission planning run through WISPR Ground Control, with WISPR Cloud providing the backend for PPK processing, data management, and fleet-level workflow integration. PPK capability requires a WISPR Cloud Subscription, with expanded processing available through the WISPR PPK Processing Upgrade (perpetual) and the WISPR PPK Photogrammetry Tool.
For programs deploying RESEPI LiDAR payloads, RESEPI PC Master Pro is the primary post-processing environment, available in one-year, two-year, and perpetual license tiers. The SurveyPro Annual Module extends PC Master Pro for survey-specific deliverable workflows. RESEPI SLAM data processing is available under a one-year license for point cloud workflows requiring simultaneous localization and mapping. The complete software stack supports data flow from airborne acquisition through to final deliverable without requiring platform changes between mission types.
Scroll to view full table →
| Software / License | Description | Term |
|---|---|---|
| WISPR Ground Control | Mission planning and ground control software for the SkyScout 2 Series | Included |
| WISPR Cloud (Base) | Fleet management, data storage, and mission logging | Annual subscription |
| WISPR Cloud (PPK) | PPK post-processing and cloud-based kinematic workflow support | Annual subscription |
| WISPR PPK Processing Upgrade | Expanded PPK processing capability for the SkyScout platform | Perpetual |
| WISPR PPK Photogrammetry Tool | Photogrammetry processing tool for PPK-corrected aerial data | Perpetual |
| RESEPI PC Master Pro License | Point cloud processing software for RESEPI LiDAR payloads | 1 Year / 2 Year / Perpetual |
| RESEPI SLAM Data Processing | SLAM-based LiDAR data processing for RESEPI payload workflows | 1 Year |
| SurveyPro Annual Module | Add-on survey module for RESEPI PC Master Pro users | Annual |
Selecting the Right SkyScout 2 Configuration for Your Program
- Deploy SkyScout 2 (Base) for programs already operating Herelink-based workflows, where a 12-mile control range is a priority and controller-level AES-256 encryption is not a procurement requirement
- Deploy SkyScout 2+ (Premium) for programs requiring Blue UAS Cleared controller compliance, AES-256 encryption, MIL-STD-810 and IP55 controller ruggedization, or the dedicated GNSS antenna mount for LiDAR payload georeferencing
- Select RESEPI LiDAR payloads for programs with point cloud, terrain modeling, or corridor mapping deliverables that exceed the output capability of photogrammetry-only workflows
- Select RTK positioning for real-time centimeter-level accuracy where a reliable NTRIP correction network is available at the deployment site
- Select PPK via WISPR Cloud for programs operating in areas with limited correction network coverage or where post-processed accuracy is required for deliverable certification
- Include WISPR Training for all program operators — training completion is required to activate the product warranty on all SkyScout 2 Series platforms
The SkyScout 2 Series gives enterprise programs a single, procurement-compliant airframe that scales across payload types, mission profiles, and operational environments without platform changes. From initial deployment through fleet expansion, both configurations are supported by a complete ecosystem of software, accessories, and service options available through Dronefly.
Dronefly carries the full WISPR SkyScout 2 Series — both aircraft configurations, the complete modular payload lineup, accessories, software licenses, and maintenance services — to support program buildout from first unit through full fleet integration.
Frequently Asked Questions
What is the difference between the SkyScout 2 and the SkyScout 2+?
Both configurations are built on the same quadcopter airframe and share identical flight performance, GNSS architecture, payload capacity, and platform features. The SkyScout 2 includes a Herelink controller with a 12-mile control range and AES128 encryption. The SkyScout 2+ includes the WISPR SkyBoss Smart Controller, which adds AES-256 encryption, a 7" 2000-nit sunlight-readable display, dual roll wheels, IP55 and MIL-STD-810 ruggedization, and an extra GNSS antenna mount for LiDAR payload integration. Enterprise programs with federal or defense procurement requirements will typically specify the SkyScout 2+.
Is the SkyScout 2 Series compliant for government and defense procurement?
Yes. Both the SkyScout 2 and SkyScout 2+ are NDAA compliant and manufactured in the United States. Both are listed on the Blue UAS Cleared List and the Green UAS Program. The SkyScout 2+ with the WISPR SkyBoss controller is specifically DCMA Blue UAS Cleared at the controller level, making it the preferred configuration for programs with strict controller-level security requirements under federal or defense procurement standards.
What payloads are compatible with the SkyScout 2 Series?
The SkyScout 2 Series supports field-swappable payloads via the S Port quick-attach system, covering photogrammetry, LiDAR, multispectral, and precision targeting configurations. The compatible lineup includes WISPR 24MP Mapper, Sony LR1 configurations, Gremsy gimbal platforms, Micasense RedEdge-P sensors, and the full RESEPI LiDAR payload series. Payloads up to 3.65 lbs. carry with no flight-time penalty; the maximum sustainable payload is 3.85 lbs.
How does RTK and PPK positioning work on the SkyScout 2 Series?
Both configurations include a Ublox ZED-F9P GNSS receiver supporting RTK via NTRIP or other RTCM correction services for real-time centimeter-level accuracy across GPS, Galileo, GLONASS, and BeiDou constellations on L1, L2, and E5 bands. PPK post-processing is available on both models through a WISPR Cloud Subscription, supported by the optional WISPR PPK Processing Upgrade and WISPR PPK Photogrammetry Tool for programs requiring post-processed kinematic accuracy.
What software and licenses does a SkyScout 2 Series program require?
Core flight operations run on WISPR Ground Control, with WISPR Cloud handling PPK processing and fleet data management. PPK workflows require a WISPR Cloud Subscription; expanded processing is available through the WISPR PPK Processing Upgrade and PPK Photogrammetry Tool. Programs deploying RESEPI LiDAR payloads require RESEPI PC Master Pro, available in one-year, two-year, and perpetual tiers, with optional SurveyPro and RESEPI SLAM add-ons for specialized deliverable workflows. WISPR Training is required to activate the product warranty on all SkyScout 2 Series platforms.
