Power Up Fast with the DJI C10000 Intelligent Battery Charger
The DJI C10000 Battery Charger is a high-powered intelligent charger engineered for professional drone operators who demand reliability, safety, and speed. With a maximum output power of 9000W and support for both fast and slow charging modes, it fully charges compatible batteries-like the DB1560 or DB800. Designed to connect to one battery at a time, this unit includes one AC cable for immediate use.
Equipped with adaptive charging logic, the charger automatically adjusts current output based on the battery's condition and status, ensuring efficient and safe charging. Even when ventilation is partially blocked, its intelligent power adjustment function keeps charging consistent.
Safety is at the forefront with built-in protections against overcurrent, overcharging, voltage spikes, overheating, and more. With a self-diagnostics system, users can easily monitor the charger's health via LED indicators or through the DJI Agras app by connecting a remote controller via USB-C.
Specifications
- Model Number: CSX702-9500
- Operating Temperature: -5° to 40° C (23° to 104° F)
- Output Channel: 1
- Input/Output:
- Input (Main): 220-240 VAC, 50/60 Hz, 24 A MAX
- Input (Auxiliary): 220-240 VAC, 50/60 Hz, 24 A MAX
- Output: 59.92 VDC MAX, 175 A MAX, 9000 W MAX
- Input (Main): 100-120 VAC, 50/60 Hz, 16 A MAX
- Input (Auxiliary): 100-120 VAC, 50/60 Hz, 16 A MAX
- Output: 59.92 VDC MAX, 60 A MAX, 3000 W MAX
- Compatible Battery: DB1560 / DB800 / T40 / T30 / T20P Intelligent Flight Battery
- Dimensions: 400 × 266 × 120 mm
- Weight: Approx. 11.4 kg
In the Box
- 1x C10000 Intelligent Power Supply
- 2x Fast Charging Cable
- 1x Conversion Cable
- 1x Slow Charging Cable (packed in a separate box)
