DJI 240W Charging Hub for Matrice 4D Series

DJI 240W Charging Hub for Matrice 4D Series

$152.00
$152.00
Sale Sold out
SKU S-DJI-M4D-CHG MPN CP.EN.00000627.01 EAN 6937224106352
  • Efficient sequential charging for three Matrice 4D batteries
  • Smart prioritization for fastest possible battery turnaround
  • Dual charging modes for 100 percent or 90 percent
  • Direct connection to DJI Power stations using SDC
  • Integrated USB-C port for professional firmware maintenance
  • Clear LED indicators for status and temperature warnings
  • Compact 16.8 to 25.5V input for field versatility
  • Safe flat-surface design for stable operation
  • Essential power hub for Matrice 4D and 4TD
Request Info / Quote ☎︎ 1 (805) 480-4033
View full details
  • Description
  • Specifications
  • In the Box
  • FAQ

DJI Matrice 4D Series 240W Charging Hub: Efficient sequential power management

The DJI Matrice 4D Series 240W Charging Hub is an essential accessory for professional operators utilizing the Matrice 4D and 4TD aircraft.

Engineered to handle the specific power requirements of 149.9Wh Intelligent Flight Batteries, this hub ensures that your power workflow is as efficient as your flight operations.

DJI Matrice 4D Series 240W Charging Hub highlights

  • Efficient sequential charging for Matrice 4D series flight batteries.
  • Versatile 90 percent Ready-to-Fly mode for quick mission turnaround.
  • Intelligent power allocation prioritizing batteries with shortest charging times.
  • Included SDC cable for seamless DJI Power Series integration.
  • Professional firmware support through a dedicated USB-C assistant port.
  • Real-time status feedback using multi-color LED pulse patterns.
  • Reliable high-capacity input supporting up to 12.1 A.
  • Safe thermal management operating between 41 and 104 degrees.

The system features a versatile mode switch, allowing users to choose between a standard 100 percent charge or a "Ready-to-Fly" 90 percent charge for immediate deployment.

Its compact design and ability to draw power from both AC adapters and portable power stations make it an ideal choice for mobile production teams and field technicians requiring reliable energy management.

The DJI Matrice 4D Series 240W Charging Hub is the definitive power solution for pilots who need to manage multiple high-capacity batteries with precision. It can sustain the intensive duty cycles required for enterprise-level aerial operations.

  • Input: SDC 16.8 V – 25.5 V, 12.1 A
  • Rated power: 240 W
  • Type of charge: sequential (up to three batteries)
  • Charging modes:Standard: charges each battery to 100%.Ready to fly: charges each battery to 90% and maintains this level
  • Compatible batteries: DJI Matrice 4D Series batteries
  • Charging temperature: 5°C – 40°C (41°F – 104°F)
  • 1x Charging Hub
  • 1x SDC Cable
Do I need the 240W adapter to use this hub?

Yes, the DJI 240W Power Adapter is required for standard operation when you are using a wall outlet to charge your Intelligent Flight Batteries. The hub is specifically tuned to the 240W power output to provide efficient sequential charging. Without this specific adapter, the hub will not have sufficient power to charge the Matrice 4D series high-capacity cells.

How does the hub handle high temperatures?

If the batteries or the hub itself exceed the safe charging temperature range, the status LED will blink yellow. In this situation, the hub will automatically pause the charging process to protect the battery cells from damage. You do not need to take any action; the charging will automatically resume once the hardware cools down to within the 41°F to 104°F operating range.

Can I update the hub's software in the field?

The charging hub features a dedicated USB-C assistant port specifically for firmware updates. By connecting the hub to a computer with the DJI Assistant software, you can ensure your charging logic and safety features are up to date. Note that this port is only for firmware and cannot be used for charging other mobile devices.

What is the purpose of the included SDC cable?

The SDC cable allows you to connect the charging hub directly to a DJI Power Series portable power station. This integration is a significant benefit for field operators who need to recharge flight batteries in remote locations where AC power is unavailable. It effectively turns your DJI Power station into a mobile charging depot for your Matrice 4D fleet.

Is it safe to leave the batteries in the hub after charging?

Once charging is complete, the status LED will turn solid green, and the hub will stop supplying active current to that port. While the hub is designed with safety protections, it is always a best practice to disconnect your Intelligent Flight Batteries from the hub once they have reached the desired charge level. This helps maintain the long-term health and stability of the battery chemistry.
