Freefly Alta X Gen2 (NDAA)

Freefly Alta X Gen2 (NDAA)

$45,650.00
$45,650.00
Sale Sold out
SKU S-FF-ALTA-X2-NDAA MPN 950-00174 EAN 0727252562635 UPC 727252562635
  • Fully NDAA-compliant heavy-lift drone for government and defense programs.
  • Complete system compliance: airframe, Pilot Pro, and Doodle Labs radio.
  • Verified 15.1 kg payload for sensors, LiDAR, and multi-payload configs.
  • Doodle Labs radio provides robust compliant RF control in the field.
  • Smart Dovetail quick-connect for Freefly and third-party payload systems.
  • Internal payload bay with Ethernet, regulated power, and onboard LTE.
  • Carbon-fiber airframe with IP43-equivalent protection and wide temperature range.
  • Standard Remote ID pre-installed for FAA and BVLOS compliance.
  • Pilot Pro with Doodle Labs radio included and preconfigured.
Request Info / Quote ☎︎ 1 (805) 480-4033
View full details
  • Description
  • Specifications
  • In the Box
  • FAQ

Freefly Alta X Gen2 (NDAA): NDAA-Compliant Heavy-Lift Drone With 33 lb Payload Capacity for Government and Defense Deployment

The Freefly Alta X Gen2 (NDAA) is a fully NDAA-compliant professional heavy-lift drone engineered for government agencies, defense contractors, and critical infrastructure operators who need maximum lift capacity, enterprise-grade autonomous flight, and a hardware stack that satisfies federal procurement requirements at the component level.

Built on a proven carbon-fiber airframe with a maximum gross takeoff weight of 34.9 kg and a verified payload capacity of 15.1 kg (33.3 lb), it is powered by a custom Skynode flight controller running Auterion Enterprise PX4 and equipped with a Doodle Labs radio link, specified by Freefly for robust and compliant remote control, that brings the entire system into NDAA compliance. Drone airframe, Pilot Pro controller, and radio link are all individually certified.

For fleet integrators and program managers who have evaluated heavy-lift platforms only to disqualify them at the compliance review, the Alta X Gen2 (NDAA) resolves that problem without sacrificing any operational capability.

The aircraft ships pre-configured and ready to fly. The Smart Dovetail quick-connect payload interface and 12mm rail mount are pre-installed, dual 12V and 24V onboard regulators supply clean power to mounted payloads, and an FPV camera feeds a live view to the Pilot Pro controller.

Key Features and Benefits

  • Full NDAA compliance: drone airframe, Pilot Pro controller, and Doodle Labs radio all certified.
  • 15.1 kg payload capacity: carries heavy sensors, LiDAR systems, and multi-payload configurations.
  • Doodle Labs radio: NDAA-compliant RF link specified for robust control in demanding environments.
  • Smart Dovetail interface: quick-connect integration with Freefly and compatible third-party payloads.
  • Internal payload bay: onboard Ethernet, regulated power, and LTE for custom mission integrations.
  • Auterion Enterprise PX4: autonomous mission planning with fleet management via Auterion Suite.
  • Pre-installed 12mm rail mount: supports full 15.1 kg payload capacity out of the box.
  • Carbon-fiber airframe: IP43-equivalent weather resistance across -20°C to +50°C operating range.
  • Standard Remote ID: pre-installed for FAA compliance and BVLOS mission authorization.
  • Pilot Pro controller: included and preconfigured with Doodle Labs radio for Alta X Gen2 (NDAA).

The internal cargo bay, accessible via removable chassis panels, supports onboard Ethernet, regulated payload power, and onboard LTE for custom sensor and data integrations without external hardware.

Auterion Mission Control handles autonomous waypoint and inspection mission planning, Auterion Suite handles fleet-level telemetry, logging, and aircraft health monitoring across multiple aircraft, and Standard Remote ID is pre-installed for FAA compliance and BVLOS authorization.

For solutions partners deploying compliant heavy-lift fleets across government and enterprise programs, the Alta X Gen2 (NDAA) is the platform designed for exactly that requirement. Batteries and charger are sold separately.

Built for Programs Where Compliance Is the First Requirement

For fleet operators and solutions partners managing government or defense UAV programs, payload capacity and autonomous flight capability are only part of the evaluation. The compliance question — does every component in the system meet NDAA requirements — comes first, and it has historically eliminated most capable heavy-lift platforms before performance even enters the conversation.

The Alta X Gen2 (NDAA) answers that question at the system level: the drone airframe, the Pilot Pro controller, and the Doodle Labs radio link are each individually NDAA compliant, and the complete system carries that compliance without hardware workarounds or aftermarket modifications.

The Auterion Enterprise PX4 flight stack, onboard LTE for Auterion Suite fleet connectivity, and internal payload bay for custom integrations are all standard — the compliance version and the full-capability version are the same aircraft.

Compatibility and System Integration

  • Freefly Flux LiDAR (O1, L1, H1): compatible via Smart Dovetail with separately sold GNSS Mount.
  • Sony LR1 camera: Smart Dovetail compatible; confirmed payload at Gen2 launch.
  • Mōvi Pro gimbal: compatible with Payload Vibration Damper and Mōvi Pro Landing Gear (sold separately).
  • Freefly Pilot Pro: included with Doodle Labs radio; preconfigured for Alta X Gen2 (NDAA).
  • Tattu Plus 1.0 12S 16Ah AS150U batteries: recommended flight batteries (sold separately).
  • Tattu TA3200 Dual-Channel Smart Charger: recommended field charger for dual-battery operations (sold separately).
  • RTK GPS Ground Station: optional upgrade for centimeter-level positioning (sold separately).
  • Auterion Mission Control and Suite: autonomous mission planning and enterprise fleet management platform.

Applications and Use Cases

  • Government and defense ISR: full system NDAA compliance satisfies federal and DoD procurement requirements.
  • Critical infrastructure inspection: compliant hardware stack clears security requirements for sensitive site operations.
  • Heavy sensor and LiDAR deployment: 15.1 kg capacity supports dual-payload and multi-sensor configurations.
  • BVLOS corridor and inspection missions: Standard Remote ID and autonomous flight support extended range operations.
  • Compliant fleet programs: Auterion Suite enables centralized management across multiple NDAA-compliant aircraft.
  • Industrial and offshore inspection: IP43-equivalent protection sustains operations across harsh environmental conditions.
  • Custom payload integration: internal bay with Ethernet and regulated power supports bespoke mission builds.

The Alta X Gen2 (NDAA) exists because compliance and capability should not require a tradeoff. With 15.1 kg of verified payload capacity, a complete NDAA-compliant hardware stack, an internal integration bay, and a full enterprise autonomous flight system, it is the heavy-lift platform that government and defense programs can procure, deploy, and scale without qualification — on the missions where that distinction matters most.

Dronefly specializes in building complete UAV system configurations for government, defense, and enterprise programs, and the Freefly Alta X Gen2 (NDAA) is the platform those programs ask for when compliance and heavy-lift capability are both non-negotiable.

When you source the Alta X Gen2 (NDAA) through Dronefly, you gain access to procurement guidance, system configuration expertise, and the fleet deployment support to match the right batteries, charger, payload, and landing gear to your operational requirements.

Reach out to Dronefly today to discuss your program needs and place your order.

Flight Controller and Payload Integration

  • Flight controller: Custom Skynode flight controller
  • Payload compatibility: Smart Dovetail-equipped payloads
  • Supported payload: LR1 for launch, with additional payloads planned
  • Integration access: Removable chassis panels

Remote ID and Compliance

  • Standard Remote ID: Yes
  • Remote ID installation: Preinstalled and configured for FAA compliance
  • BVLOS compliance: FAA compliant for Beyond Visual Line of Sight operations
  • FCC DA 25-1086: Yes
  • FCC status: Ships with FCC-approved critical components

Power and Battery System

  • Battery system: Upgraded smart batteries with AS150 connectors
  • Battery benefit: Improved flight time estimation
  • Onboard power: 12 V and 24 V regulators

Pre-Installed Accessories

  • 12 mm rail mount: Supports payloads up to 35 lbs
  • Smart Dovetail isolated mount: Supports LR1 payload or other Smart Dovetail payloads up to 3.3 lbs
  • Landing gear: Skid landing gear with 380 mm / 14.97 in quick-release legs
  • FPV camera: Feed viewable on Pilot Pro

Transport Case

  • Included case: Alta X Gen2 case
  • Case compatibility: Alta X Gen2 with 12 mm rails and Smart Dovetail mount installed
  • Case storage: Pilot Pro
  • Case storage: Spare ActiveBlade propellers
  • Case storage: Skid landing gear with medium legs

Controller

  • Controller: Freefly Pilot Pro Controller
  • Radio system: Doodle Labs RF
  • Control benefit: Precise and robust NDAA drone control

NDAA and Blue UAS Status

  • NDAA status: Yes
  • Alta X Gen2 drone: Compliant
  • Pilot Pro: Compliant
  • Doodle Labs radio link: Compliant
  • DIU Blue status: No
  • Alta X Gen2 drone: In process for approval
  • Pilot Pro Controller: Compliant
  • Doodle Labs radio link: Compliant
  • 1x Alta X Gen2 Airframe (Standard Remote ID, with Props Installed)
  • 1x Extra Bits Kit
  • 1x AS150U Fused Adapter for Safe Bench Configuration
  • 2x Power Distribution Replacement Fuse (10A)
  • 1x Spare Battery Retention Strap
  • 1x USB-C to USB-C Cable (1.82 m / 6 ft)
  • 1x 64GB USB-C Thumb Drive
  • 4x ActiveBlade Bumper Replacements
  • 4x Balance Lead Sticker Covers for Tattu AS150U Batteries (Wet Weather)
  • 1x Skid Landing Gear (380 mm / 14.97 in Legs Only)
  • 1x 12mm Rail Kit (Installed)
  • 1x Smart Dovetail with Isolated Mount for up to 1.5 kg Freefly Payloads (Installed)
  • 1x Pilot Pro Controller (Preconfigured for Alta X Gen2 with Doodle Labs Radio)

Does Not Include

  • Batteries and chargers are not included
  • Recommended minimum: one dual-channel charger and six Alta X Gen2 batteries per aircraft
  • Add one pair of batteries for each additional planned flight beyond three flights
  • Additional chargers increase charging throughput efficiency

Additional Hardware Required for Certain Applications

  • Cinema or vibration-damped payloads: Payload Vibration Damper
  • Cinema or vibration-damped payloads: Skyview Landing Gear
  • Cinema or vibration-damped payloads: Mōvi Pro Landing Gear
  • Cargo applications: Cargo Landing Gear
  • Cargo applications: Application-specific accessories
  • Cargo applications: Short Quick Release Mount
What is the Freefly Alta X Gen2 (NDAA) and who is it designed for?

The Freefly Alta X Gen2 (NDAA) is a fully NDAA-compliant professional heavy-lift drone built for government agencies, defense contractors, and critical infrastructure operators who require component-level NDAA compliance across the entire system.

It carries up to 15.1 kg (33.3 lb) on a proven carbon-fiber airframe with a maximum gross takeoff weight of 34.9 kg, powered by a custom Skynode flight controller running Auterion Enterprise PX4. The Doodle Labs radio link — specified by Freefly for robust and compliant remote control — replaces the Herelink radio used in non-NDAA variants, bringing the full system into compliance at the component level: drone airframe, Pilot Pro controller, and radio link are each individually certified.

What does full system NDAA compliance mean for the Alta X Gen2 (NDAA)?

Full system NDAA compliance means that every hardware component in the system — not just the airframe — meets NDAA requirements individually. For the Alta X Gen2 (NDAA), the drone airframe is NDAA compliant, the Pilot Pro controller is NDAA compliant, and the Doodle Labs radio link is NDAA compliant.

This component-level compliance is critical for procurement officers who must verify compliance across every element of the system, not just the aircraft itself. Note that DIU Blue UAS framework approval for the drone airframe is still in process at the time of this listing — Dronefly can advise on current approval status.

What payload capacity does the Alta X Gen2 (NDAA) support and what payloads are compatible?

The Alta X Gen2 (NDAA) has a verified maximum payload capacity of 15.1 kg (33.3 lb) per official Freefly technical documentation, with a maximum gross takeoff weight of 34.9 kg. The 12mm rail kit pre-installed on the aircraft supports the full payload capacity for industrial sensor and heavy payload configurations.

Compatible payloads include the Freefly Flux LiDAR series (O1, L1, H1) via Smart Dovetail with a separately sold GNSS Mount, the Sony LR1 camera via Smart Dovetail, and the Mōvi Pro gimbal with Payload Vibration Damper and appropriate landing gear. Dronefly can assist with configuring the right payload combination for your specific mission requirements.

What does the internal payload bay support and how is it accessed?

The internal cargo bay is accessed by removing the Alta X Gen2's chassis panels. It supports onboard Ethernet connectivity, regulated payload power, and onboard LTE for remote connectivity, enabling operators to install computing hardware, network switches, or communication modules without external mounting.

This is particularly relevant for complex government inspection programs requiring real-time data transmission, autonomous workflows requiring onboard edge computing, or remote operations where LTE connectivity is a mission requirement. The 12V and 24V onboard regulators supply clean regulated power to both externally mounted and internally installed systems.

Does the Alta X Gen2 (NDAA) include batteries and a charger?

No. The Alta X Gen2 (NDAA) ships without batteries or a charger. Freefly recommends at least one pair of Tattu Plus 1.0 12S 16Ah AS150U batteries per aircraft — each flight requires two batteries — and the Tattu TA3200 Dual-Channel Smart Charger for field operations.

For operators planning more than three flights without access to field charging, Freefly recommends one additional battery pair per planned additional flight. Each charger handles two batteries simultaneously, and additional chargers reduce overall field charging throughput time. Dronefly can advise on the right battery and charger configuration for your program's operational tempo.

Is the Alta X Gen2 (NDAA) approved under the DIU Blue UAS framework?

Not yet. At the time of this listing, the Alta X Gen2 drone airframe is in process for DIU Blue UAS approval. The Pilot Pro controller and Doodle Labs radio link are both DIU Blue compliant.

Operators whose procurement specifically requires DIU Blue UAS framework approval — rather than NDAA compliance alone — should confirm current approval status with Dronefly before purchasing, as the approval status may have been updated since this listing was published.

Dronefly can advise on the current compliance standing and help evaluate whether this platform meets your specific program requirements.
