• JZ PT4 Four Drop Kit for DJI Matrice 350 RTK & Matrice 300 RTK
  • JZ PT4 Four Drop Kit
  • JZ PT4 Four Drop Kit for DJI Matrice 350 RTK/Matrice 300 RTK
1 3

JZ Drones PT4 Four Drop Kit for M350/M400

JZ Drones PT4 Four Drop Kit for M350/M400

$999.00
$999.00
Sale Sold out
SKU S-NB-JZ-PT4 MPN JZ.DK.0004.01 EAN 6976509040066
  • Lightweight 120 g design minimizes flight performance impact.
  • Four-hook system enables flexible multi-point payload deployment.
  • 3 kg per mount supports varied payload delivery needs.
  • 12 kg total capacity supports multi-item mission operations.
  • Laser-assisted aiming improves targeting accuracy during release operations.
  • SkyPort V2 interface enables fast installation and integration.
  • Real-time monitoring provides clear hook status during operation.
  • Independent release control supports sequential payload deployment.
  • Power-free mounting simplifies setup without system power requirements.
Request Info / Quote ☎︎ 1 (805) 480-4033
View full details
  • Description
  • Specifications
  • In the Box
  • FAQ

JZ Drones PT4 Four Drop Kit: Lightweight Four-Stage Payload Release System for Controlled Multi-Drop Operations

The JZ Drones PT4 Four Drop Kit is a DJI PSDK-based aerial payload delivery system designed for precise, repeatable multi-payload deployment using DJI Matrice platforms, including the Matrice 300 RTK, Matrice 350 RTK, and Matrice 400. It mounts via DJI SkyPort V2 and integrates directly with DJI Pilot 2, allowing operators to monitor payload status and control release in real time.

The system supports four independent hooks with flexible release control, making it suitable for emergency response, logistics, and industrial operations. With a lightweight 120 g build, laser-assisted targeting, and no external power requirement, it enables efficient aerial delivery workflows.

Key Features and Benefits

  • Four-hook system: supports 4 independent mounts for flexible payload deployment
  • Payload capacity: supports up to 3 kg (6.6 lbs) per hook
  • Total capacity: supports up to 12 kg (26.4 lbs) combined payload
  • SkyPort V2 interface: enables fast installation with secure mounting connection
  • Pilot 2 integration: allows real-time monitoring and individual hook control
  • One-key release: deploys all payloads simultaneously when mission requires
  • Lightweight design: weighs 120 g reducing payload impact on aircraft
  • Laser-assisted aiming: improves targeting accuracy during payload deployment
  • Power-free mounting: allows payload setup without powering the aircraft

Applications and Use Cases

  • Search and rescue: delivers emergency supplies directly to individuals in distress
  • Fire response: deploys payloads into hazardous or hard-to-reach fire zones
  • Emergency logistics: transports critical supplies to isolated operational areas
  • Utility operations: supports delivery of small tools or equipment onsite
  • Disaster response: enables controlled supply drops during emergency situations
  • Industrial delivery: facilitates repeatable payload deployment across job sites

The PT4 is designed for operators who require reliable and controlled payload delivery across mission types. Its lightweight structure, multi-hook system, and real-time control improve efficiency while maintaining deployment accuracy.

When you purchase from Dronefly, you gain a UAV solutions partner focused on long-term operational success. From integration to deployment, Dronefly supports your mission—order the PT4 Four Drop Kit from Dronefly today.

General Specifications

  • Electrical interface: DJI SkyPort V2
  • Dimensions: 58 × 58 × 54 mm
  • Weight: 120 g
  • Rated power: 10 W
  • Protection rating: IP4X

Compatibility & Installation

  • Compatible aircraft: Matrice 400, Matrice 350 RTK, Matrice 300 RTK
  • Number of mounts: 4 independent hooks
  • Installation: gimbal interface quick release
  • Control system: DJI Pilot 2

Payload Capacity

  • Maximum single mount load: 3 kg (subject to aircraft limits)
  • Maximum total payload: 12 kg (subject to aircraft limits)

Drop Functionality

  • Independent or simultaneous multi-drop capability
  • No restriction on delivery sequence
  • Laser-assisted targeting
  • Single-point drop and one-button full release

Environmental Specifications

  • Operating temperature: -10 °C to 50 °C
  • Storage temperature: -20 °C to 60 °C
  • 1x JZ PT4 Four-Drop Kit
  • 1x Protective Carrying Case
  • 4x Hooks
  • 4x Wire Rope
  • 1x Adapter Protection Cover
  • 1x Product Manual
  • 1x Warranty Card
What does the JZ Drones PT4 Four Drop Kit enable during missions?

The JZ Drones PT4 Four Drop Kit enables precise aerial delivery of multiple payloads during flight. Operators can release items individually or all at once. This improves efficiency in emergency, logistics, and industrial operations.

How is the JZ Drones PT4 Four Drop Kit installed on DJI drones?

The system mounts using the DJI SkyPort V2 interface. This provides a secure connection and allows quick installation and removal. It integrates directly with supported DJI Matrice aircraft.

Can the JZ Drones PT4 Four Drop Kit release multiple payloads in one flight?

Yes, it includes four independent hooks that allow multiple payloads to be carried. Each hook can be released individually or simultaneously. This supports flexible multi-drop missions.

Does the JZ Drones PT4 Four Drop Kit require an external battery?

No, the system draws power directly from the drone through the SkyPort interface. This eliminates the need for additional batteries. It helps reduce weight and simplifies deployment.

Is the JZ Drones PT4 Four Drop Kit accurate for targeted delivery?

Yes, the built-in laser-assisted aiming helps identify the drop zone. Combined with real-time control through DJI Pilot 2, it improves delivery precision. This is useful for high-accuracy operations.
